What is the new AC500 & B300S power supply system?
You can call it a home backup power plant. Prepare for power outages, run your off-grid home, or simply save on your electric bill. The choice is yours.
You can also call it a portable power plant. You can take it with you wherever you go. So you always have power for all your activities. You can also take the modular B300S battery storage with 3KWh power storage each, for camping. Or in the caravan. Or all at once. And that up to a fabulous 18.4 KWh of electricity storage distributed over 6 batteries that simply work like the rest of the system, plug & play.
Or power your home 24/7
The AC500 converter delivers a high quality constant sine wave to your 230V/400V AC and acts as your home power supply. It can handle loads up to 10KW / 10'000 Watt. This ensures that your plugged-in devices can operate in full functionality and power.
Extendable power supply
The BLUETTI AC500 can serve external battery packs modularly, and expand this from a minimum 3KWh power storage capacity up to a whopping 18.4 KWh, depending on your needs or budget. From an emergency generator to an off-grid power source for home, cottage or off-road, this home generator covers all your power needs. And as a portable power station because you can quickly set up and tear down to set up again elsewhere, a top performer.
5000W pure sine wave inverter (10'000W peak load)
Expandable up to 18'432Wh with 6×B300 or B300S modules
7 ways to charge (AC/solar power/car/generator/battery/double AC/AC+solar power)
16 Outputs to operate all your devices. Including 2 wireless pads with 18W for wireless charging of Phones & Tablets.
3000W Max. Solar Input
8000W Max. Fast Dual Charging (Solar + AC Adapter over mains at the same time).
Smart App Control & Monitor
24/7 UPS Home Backup - switchover time under 10 milliseconds in case of power failure, enough to keep servers online as well
You can always unhook a battery module, load it into your car or camper, and take a top-of-the-line portable power bank with you wherever you go with 3KWH of power. Or even two. three or four. or anything...
8000W Fast Dual-Charge
Connect the power adapter and solar panels, then you can charge BLUETTI AC500 with an amazing input power of 8000W. Charge this power pack before a spontaneous trip and you are ready to go.
8000W = 5000W AC + 3000W solar and in just 50 minutes you will have your 6KWh energy storage 80% charged with two B300S. In 65 minutes to 100%. That's what we call power.
Is it possible to pair 2 AC500 ?
In the 230V range no. Instead of coupling 2x an AC500 with 6xB300S each (with 18.4 KWh each to 36.8 KWh), we recommend for larger off-grid solutions to use 2 systems in parallel, e.g. for different circuits or floors, and define them individually for the house circuits to be fed. If you need help or on-site support, you can contact us. If you have a larger energy storage need, we recommend the hybrid solution EP600 with up to 80KWh as a fixed house installation.
Multiple sockets for all needs
The NEMA TT-30 and 12V/30A DC connector are perfect for RV & Van Life. Wireless chargers allow you to charge compatible smartphones, headphones, etc., as well as computers directly via UBS-C. Total 16 outputs for every need.
Thanks to Bluetti's state-of-the-art high-performance LiPO4 battery technology, which gives you 80% remaining power even in 10 years after 3500 recharge cycles, we give you 4 years free warranty for AC500 Powerstation and B300/B300S battery expansion modules. Optional warranty extensions can be requested.
Note on battery expansion modules compatibility
The Bluetti AC500x Power Station is compatible with both the 3KWh Bluetti B300S battery expansion module designed for the AC500 and the B300 module. The B300S offers a higher output power than the B300.
